Autonomous Forklift Unmanned Pallet Handling Robot

Core Selling Points

1.1500kg Heavy Load & 110mm Stable Lifting

Standard 110mm lifting stroke, thickened high-strength pallet fork, stably lift 1.5 tons pallets, suitable for heavy industrial pallet batch handling.

2.Auto & Manual Dual Intelligent Control

Unmanned automatic scheduling for long-distance fixed route circulation; manual driver control handle for temporary emergency pallet transfer, one machine two functions.

3.4G/WiFi Multi-robot Cluster Scheduling

Remote PC/tablet fleet management, multiple forklifts run collaboratively, timed patrol, multi-point simultaneous pallet delivery.

Core Product Advantages

1. Multi-scene Adaptive Navigation Solution

Different from single-mode unmanned forklifts, WD-FT1500 provides four navigation options: marker-free free laser navigation without any ground construction for new factories; low-cost magnetic track navigation for old workshops; mixed navigation for complex mixed layout; follow mode for small batch flexible production, fully cover all customer transformation demands.

Equipped with independent manual driving handle, operators can switch to manual mode at any time for temporary pallet transfer without preparing separate manual pallet jacks; automatic mode supports automatic elevator, rolling shutter passing to complete cross-area warehouse circulation.

3. All-round Safety Anti-collision System

From top LiDAR long-distance detection, side photoelectric sensors to bottom full safety touch edge, multi-layer anti-collision protection. When obstacles or pedestrians are detected, the robot automatically decelerates, stops and triggers warning light reminder, effectively avoid pallet collision and goods damage.

Product Parameters

FAQ

Q1: What is the maximum rated load of WD-FT1500 autonomous forklift unmanned pallet handling robot?

A1: The rated load capacity reaches 1500kg, standard lifting height 110mm, can stably transport standard industrial pallets with heavy goods.

Q2: Does WD-FT1500 support both automatic and manual operation?

A2: Yes. It has independent manual driving handle for temporary pallet transfer; automatic navigation mode realizes unmanned fixed route circulation, two modes can be freely switched.

Q3: Can multiple WD-FT1500 forklifts work collaboratively at the same time?

A3: Yes, 4G+WiFi dual wireless communication supports multi-robot cluster fleet scheduling, remote one-key task assignment and timed patrol pallet delivery.

Product Operation Instructions

1.Pre-operation Inspection

Check fork surface for deformation, confirm emergency stop button is reset, profile warning light shows standby green.

Verify battery power; trigger charging task if low power alarm appears.

Clean LiDAR, photoelectric sensor and safety touch edge surface, remove dust and debris.

Confirm warehouse aisle width ≥2200mm, clear obstacles on driving route.

Mode 1: Automatic Unmanned Navigation Mode

Complete warehouse map building and delivery task editing on remote scheduling platform in advance.

Align pallet entry with fork, lift to 110mm height to separate pallet from ground, balance goods center of gravity.

Operate touch screen to select pre-set task and start automatic operation.

Robot runs along planned route with real-time obstacle avoidance; auto return charging dock after task completion or low power.

Mode 2: Manual Driver Control Mode

Pause all background automatic scheduling tasks first.

Hold the built-in driving handle, manually control forward, backward, turn and lifting/lowering of forks.

After finishing temporary pallet transfer, exit manual mode and resume automatic navigation tasks.

3. Daily Shutdown & Storage

Finish all delivery tasks, send robot back to charging dock for supplementary charging.

Clean fork, sensors and wheel debris, wipe LiDAR lens with soft lint cloth.

Long-term idle storage: fully charge battery, cut off main power, charge once every 15 days to protect battery life.
